Product Detail
|
Kev piav qhia |
Chav tsev |
Tus nqi Parameter |
|
Rated load |
1100 |
kg |
|
Lub thoob muaj peev xwm |
0.6 |
m³ |
|
Kev ua haujlwm loj |
3550 |
kg |
|
Rated zog ntawm lub cav |
61.3 |
kW |
|
Rated ceev ntawm lub cav |
2400 |
r / min |
|
Muab pov tseg qhov siab |
2800 |
mm |
|
Cov khoom pov tseg |
1036 |
mm |
|
Wheelbase |
1200 |
mm |
|
Log tread |
1000 |
mm |
|
Maximum breakout quab yuam |
Ntau tshaj los yog sib npaug rau 30 |
kN kev |
|
Maximum traction quab yuam |
Ntau dua lossis sib npaug li 28 |
kN kev |
| Zuag qhia tag nrho Dimensions (L * W * H) | 3760*2000*2040 |
mm |
|
Ceev |
12/19 (yeem ob -ceev) |
km/h |
Basic Configuration thiab Suspension System
-
Basic Configuration
Qhov no yog tus qauv nruab nrab -duty Side Raise (SR) skid steer loader, nrog rau nws cov kev teeb tsa tseem ceeb tsim nyob ib puag ncig kev ntseeg siab, siab tawg quab yuam, thiab kev hloov pauv ceev.
Lub Hwj Chim & Tsav Tsheb: Tsav los ntawm ~ 55 kW hauv tsev siab - lub zog siv hluav taws xob siv hluav taws xob, nws siv lub tshuab xa hluav taws xob hydrostatic rau kev tswj kom nrawm nrawm thiab nrawm nrawm -steer maneuverability.
Kev Ua Haujlwm: Kev Sib Txuas Sib Txuas (SR) yog nws qhov kev txhais lus, xa cov kev khawb zoo tshaj plaws thiab kev quab yuam zoo tshaj plaws rau kev ua haujlwm hnyav. Nws los ntawm tus qauv nrog lub siab - ntws hydraulic system thiab ceev - txuas txuas, ua kom muaj kev hloov pauv ntawm ntau cov hydraulic txuas hauv vib nas this kom muaj tseeb ntau -functionality.
Chaw Ua Haujlwm Chaw Ua Haujlwm: Ua kom muaj kev nyab xeeb - ntawv pov thawj ROPS / FOPS cab nrog kev paub txog ob- qib tswj. Muaj kev nplij siab xws li cua txias.
- Qhov System Suspension
-
Cov qauv no los ntawm cov qauv uas tsis muaj elastic ncua kev kawm ntawv, kev txiav txim siab tsim kev xaiv raws li nws cov haujlwm tseem ceeb.
Standard Form: Nws siv ib tug nruj ncua kev kawm ntawv, qhov twg cov axles yog bolted ncaj qha mus rau lub ntsiab ncej. Qhov no muab lub platform ruaj khov thiab tswj tau meej thaum lub sijhawm nqa hnyav, thauj khoom, lossis siv cov cuab yeej cuam tshuam xws li cov khoom tawg.
Primary Trade-off: Caij kev nplij siab yog txi. Kev vibrations thiab shocks los ntawm cov av tsis sib xws yog ncaj qha mus rau tus ncej thiab tus neeg teb xov tooj thaum mus ncig.
Kev daws teeb meem: Tus neeg teb xov tooj kev nplij siab tuaj yeem txhim kho tau zoo los ntawm kev xaiv lub rooj zaum kho tshuab, uas yog tus nqi - cov txiaj ntsig tau txais txiaj ntsig zoo. Ntau dua chassis ncua kev kawm ntawv tej zaum yuav muaj nyob rau hauv siab dua - qauv kawg.
Yeem Configurations
Peb lub tuam txhab
FAQs
Q: Dab tsi yog qhov txawv ntawm qhov "Side Raise" linkage thiab "Vertical Lift"?
A: Cov"Side Raise" xav tias muaj zog dua rau kev khawbthiab pov cov khoom kom deb ntawm nruab nrab -qhov siab, thaum"Vertical Lift" nqa siab dua thiab ncajrau leej stacking.
Q: Vim li cas lub tsheb thiaj li tsoo txawm tias qhov nrawm nrawm? Ib qho kho?
A: Nws muajtsis muaj shock absorbers (nruj ncua kev kawm ntawv)rau txoj haujlwm ruaj khov. CovQhov zoo tshaj plaws kho yog ntxiv lub rooj zaum ncua kev kawm ntawv, uas absorbs kev co rau tus neeg teb xov tooj.
Q: Puas yog qhov ceev - txuas txuas yooj yim rau ib tus neeg siv?
A: Yog, nws yog ib qho tseem ceeb feature.Cov neeg ua haujlwm tuaj yeem ruaj ntseg hloov cov ntawv txuas feem ntau hauv qab ib feeb los ntawm lub cab uas siv lub tshuab hydraulics.
